120kW Dry Cooler with Hotbox Liu /Hotbox Liu Plus

Complete package for fast-and easy installation of immersion cooling system without modifying miners. The cooling package designed for effective removal of heat with dry coolers.

120kW Dry Cooler with Hotbox Liu /Hotbox Liu Plus

Complete package for fast-and easy installation of immersion cooling system without modifying miners. The cooling package designed for effective removal of heat with dry coolers.

Learn more

Order

The immersion fluid has a higher heat absorption capacity than the surrounding air. Giving you the potential of higher hash rate due to overclocking (which is unattainable with air cooling) and faster return on investment.

The 120kW Dry Cooler comes with 3 units of Hotbox Liu as a complete 18-pack turn-
key immersion system or with 2 units of a Hotbox Liu Plus as a complete 12-pack turn-key immersion system for extreme overclocking.

The 18-pack package includes: 3 units of aluminum enclosures, 6 heat exchangers, 3 units of 1-phase 6-way C20 4kW PDU, 18 stand-offs, power cables, switches, 120kW Dry Cooler with pumps, valves, expansion tank, regulator valve, fittings.

The 12-pack package includes: 2 aluminum enclosures of Hotbox Plus, 4 heat exchangers, 12 customized 8kW PSUs, 3-phase 12-way C20 8kW PDUs, 12 stand-offs, power cables, switches, 120kW Dry Cooler with pumps, valves, expansion tank, regulator valve, fittings.

Contact us to order

Technical Specifications:

120kW Dry Cooler

Heat Transfer 35°/95F: 120kW, Heat Transfer 25°/95F: 140kW,
Dimensions: 2400 x 1400 x 500 mm/ 94.49”x55.12”x19.69”,
Fans & Noise: 3x500 mm/ 16.69”/58-68dB(A),
Power: 720/550W per fan,
Power Standard: 400V/3Ph/50hz (1.4-0.9A 720-550W) or 460V/3ph/60hz (1.64A 1060W),
Fittings: 2″ DN50,
Fluid In/Out: 60C/40C / 140F/104F,
Weight: 50kg/ 110.23Lb.

Hotbox Liu:

Material: aluminum
Dimensions: 18"x20"x29" (678мм x 807 x 678мм) x 2
Dielectric fluid volume: 41gal x 2
Expected OC: 4000W
Package: 2 aluminum enclosures, 4 heat exchangers, 1-phase 6-way C20 4kW PDUs, 12 stand-offs, power cables, switches.

Hotbox Liu Plus:

Dimensions: 18"x20"x29" (678мм x 807 x 678мм) x 2
Dielectric fluid volume: 41-gal x 2
Expected OC: 6000W
Package: 2 aluminum enclosures, 4 heat exchangers, 12 customized 8kW PSUs, 3-phase 12-way C20 8kW PDU, 12 stand-offs, power cables, switches.
