70kW Dry Cooler with Hotbox Liu /Hotbox Liu Plus

Complete package for fast-and easy installation of immersion cooling system without modifying miners. The cooling package designed for effective removal of heat with dry coolers. We supply you with hydraulic and electrical components.

70kW Dry Cooler with Hotbox Liu /Hotbox Liu Plus

Complete package for fast-and easy installation of immersion cooling system without modifying miners. The cooling package designed for effective removal of heat with dry coolers. We supply you with hydraulic and electrical components.

Learn more

Order

The immersion fluid has a higher heat absorption capacity than the surrounding air. Giving you the potential of higher hash rate due to overclocking (which is unattainable with air cooling) and faster return on investment.

The 70kW Dry Cooler comes with 2 units of Hotbox Liu as a complete 12-pack turn-key immersion system or with 1 unit of a Hotbox Liu Plus as a complete 6-pack turn-key immersion system for extreme overclocking.

The 12-pack package includes: 2 units of aluminum enclosures, 4 heat exchangers, 2

units of 1-phase 6-way C20 4kW PDU, 12 stand-offs, power cables, switches, 70kW Dry Cooler with pumps, valves, expansion tank, regulator valve, fittings.

The 6-pack package includes: one aluminum enclosure of Hotbox Plus, 2 heat exchangers, 6 customized 8kW PSUs, 3-phase 12-way C20 8kW PDU, 6 stand-offs, power cables, switches, 70kW Dry Cooler with pumps, valves, expansion tank, regulator valve, fittings.

Contact us to order

Technical Specifications:

70kW Dry Cooler:

Air inlet: 35C/95F, Medium inlet:60C/140F, Medium outlet: 52C/125F, Et glycol: 38%, Pressure drop: 4.82psi,
Capacity: 68.22kW, Volume flow: 4.9m3/h/ 0.268cfm, Fin spacing: 2.9mm/ 0.09”. Fan 1x 500mm/ 16.69”,
Electrical source: 400V/3Ph/50Hz, Fan Motor Total:2,
Air flow: 14770m3/h / 807.63cfm,
Connection: D, Sound Pressure Level: 55DB(A)10M,
Exterior dimension: 2015x520x828 mm/ 79.33”x20.47”x32.6”,
Weight: 97kg/ 213.85Lb

Hotbox Liu:

Material: aluminum
Dimensions: 18"x20"x29" (678мм x 807 x 678мм) x 2
Dielectric fluid volume: 41gal x 2
Expected OC: 4000W
Package: 2 aluminum enclosures, 4 heat exchangers, 1-phase 6-way C20 4kW PDUs, 12 stand-offs, power cables, switches.

Hotbox Liu Plus:

Material: aluminum
Dimensions: 18"x20"x29" (678мм x 807 x 678мм)
Dielectric fluid volume: 41 gal
Expected OC: 6000W
Package: one aluminum enclosure, 2 heat exchangers, 6 customized 8kW PSUs, 3-phase 12-way C20 8kW PDU, 6 stand-offs, power cables, switches.

Product gallery
